    Euchner N01R550-M Precision Single Limit Switch N01, Roller Plunger 084903

    Ask Lasest Price
    Brand Name : Euchner
    Model Number : N01R550-M
    Price : variable
    Payment Terms : T/T
    Supply Ability : 30PCS/WEEKS
    Delivery Time : Negotiate
    • Product Details
    • Company Profile

    Euchner N01R550-M Precision Single Limit Switch N01, Roller Plunger 084903

    Euchner N01R550-M Precision Single Limit Switch N01, Roller Plunger 084903


    Electrical connection values

    Connection cross section0.14 ... 1 mm²
    Rated insulation voltage Ui250 V
    Rated impulse withstand voltage Uimp2.5 kV
    Utilization category
    DC-132 A 24 V
    AC-152 A 230 V
    Short circuit protection according to IEC 60269-16A gG
    Switching current
    min. at DC 24V10 mA
    thermal rated current Ith6 A

    Mechanical values and environment

    Approach speed0.01 ... 50 m/min
    Connection type
    1 xM12 x 1.5
    Number of door position NC contacts1 Changeover contact
    Number of door position NO contacts1
    Actuating element
    Slide bearing metalRoller plunger
    Actuating force15 ... 20 N
    Installation orientationany
    Mechanical life10 x 10⁶
    Switching principleChangeover contact with snap-action function
    Degree of protectionIP67
    Ambient temperature-5 ... +80 °C
    Material
    ContactSilver alloy, gold flashed
    HousingAnodized die-cast alloy
